63
NICE - MIRIAM - CRISTAL - PRETTY - DIANA - KRISS - MARY
EN
• Recompose all.
9.5
ELECTRIC CONNECTION
Warning: the appliance must be installed by an authorized technician!
• The electric connection occurs through a cable with plug put in an electric socket which is able to
support charge and tension specific of every model, as described in the technical datas table (see
FEATURES a pag. 87
).
• The plug must be easily accessible when the appliance is installed.
The cable must not get in touch with the fume exhaust pipe and nor with every other
part of the stove.
• Please further assure you that your network is endowed with an efficient earth connection: if it does not
exist or if it is not efficient, please endow you with one in compliance with the law.
• Connect the supply cable first on the back of the stove (see
Fig. 19 a pag. 63
) and then at a wall
electric socket.
Fig. 19 - Electric socket with master switch
• The master switch O/I (see
Fig. 19 a pag. 63
) is to open only to switch the stove on, otherwise it is
advisable to keep it off.
• Do not use extension cables.
• If the feeder cable is damaged, it must be replaced by an authorized technician.
• When the stove is not going to be used for a long period of time, it advisable to remove the plug from
the socket on the wall.
9.6
CONNECTION TO THE EXTERNAL THERMOSTAT
The stove works through a thermostat probe placed in its inner. If you desire, the stove can be connected
to an external room thermostat. This operation must be executed by an authorized technician.
For connection see
WIRING SCHEME a pag. 83
:
• external thermostat: set up a temperature which is round 7°C.
• External chronothermostat: set up a temperature which is round 7°C and desable the chrono functions
from the menu 03-01.
